Products

Wavefront Analyzer


BOJIONG focuses on providing high-end optical inspection and measurement equipment. It is the leading domestic manufacturer and suppliers of Wavefront Analyzers in China.The wavefront analyzer was developed by a team of professors from Zhejiang University and Nanyang Technological University in Singapore. It has domestic patented technology and combines diffraction and interference to achieve four-wave transverse shear interference in a common path. It has super detection sensitivity and vibration resistance. performance, it can achieve real-time, high-speed dynamic interferometry and three-dimensional real-time imaging without vibration isolation. We have strong technical support, good quality and service guarantee.


The BOJIONG wavefront analyzer is mainly composed of a randomly coded hybrid grating and a CCD. It can obtain a high-contrast interference pattern at any observation position and achieve continuous adjustment of wavefront detection sensitivity and dynamic range. It has a compact structure, simple instrument adjustment, stable interference fringes, and can realize wavefront detection of any distortion. It can be used in wavefront sensing, photolithography projection objective wave aberration measurement and other fields. Single-channel light self-interference, no reference mirror required, 2nm RMS high phase resolution, extremely strong vibration resistance, no need for optical vibration isolation, realizing simple and fast interference light path construction, supporting collimated beams, large NA convergent beams, It is suitable for the 200nm~1500nm band and supports customized wavefront analyzers for short-wave ultraviolet, far-infrared and ultra-far-infrared special wavebands.


BOJIONG wavefront analyzer can be used for laser beam quality analysis, plasma flow field detection, real-time measurement of high-speed flow field distribution, optical system image quality evaluation, microscopic profile measurement and quantitative phase imaging of biological cells, etc. It can perform real-time dynamic detection and three-dimensional real-time imaging, and is designed to provide reliable data for optical processing companies, major universities, measurement units, researchers at scientific research institutions, and relevant personnel writing scientific papers.







View as

3D White Light Profilometer

3D White Light Profilometer

The 3D White Light Profilometer can promptly measure the micro-morphology and roughness of the smooth surface of components, and the software can display 3D effects. It uses common-path interferometric measurement technology, which has excellent seismic resistance and immunity to external interference, making it suitable for environments such as workshops and outdoors. The use of ordinary imaging objectives simplifies the operation process and improves measurement efficiency. While ensuring high-precision measurement, it offers competitive pricing to meet the needs of different users. The powerful digital wavefront reconstruction image processing software can provide clear 3D morphological images, facilitating analysis and reporting.
Portable 3D Profilometer

Portable 3D Profilometer

When customers expressed the desire to measure without moving the object under test, BOJIONG promptly introduced the Portable 3D Profilometer. We have always placed customer satisfaction and a deep appreciation for the talent that propels us forward at the core of our business philosophy. We tirelessly work to strengthen our foundation and refine our service offerings. With a global customer base that spans from Europe and America to Asia and our local markets, we cherish the long-standing, positive relationships we have cultivated. We extend our hand in partnership, eager to forge a path to the future together.
Flat Panel Window Distortion Detector

Flat Panel Window Distortion Detector

When the object being tested is small or thin, it needs to be stood up for detection, and we have introduced the Flat Panel Window Distortion Detector to meet the needs of our customers. For many years, we have been focusing on wavefront interference detection technology. Our products are widely used in the fields of optical manufacturing, aerospace, biomedical, and energy research, helping customers to conduct precise optical performance measurement and analysis, thereby improving product quality and production efficiency. Our products have advanced R&D technology and a good price advantage, and we look forward to becoming your long-term partner in China.
Laser Planar Interferometer

Laser Planar Interferometer

In the category of testing, some large and thick glass surfaces require the measurement of scratches and spots. BOJIONG has introduced the Laser Planar Interferometer. This device can quickly inspect the flat and smooth glass surfaces. Combined with software algorithms, it can quickly mark various defects. At the same time, the software supports the export of raw measurement data for customers to conduct data analysis and research later.Any inquiries and problems please feel free to send emails to us and we will reply you soon.
Transient Aerodynamic Flow-field Analyzer

Transient Aerodynamic Flow-field Analyzer

To effectively enhance the accuracy of wind tunnel and flow field measurement data, BOJIONG has introduced the Transient Aerodynamic Flow-field Analyzer. We are actively developing and expanding the application field of interferometric measurement technology. Ensuring that our products continue to evolve to meet the diverse needs of our customers.
Ultraviolet Wavefront Analyzer

Ultraviolet Wavefront Analyzer

BOJIONG Optoelectronics is dedicated to helping customers with accurate optical performance measurement and analysis to improve product quality and production efficiency. We are now launching the Ultraviolet Wavefront Analyzer. Our products and services are extensively used in fields like optical manufacturing, aerospace, biomedical, and energy research. We are constantly expanding our production capacity, enhancing our technical strength, and have established a robust corporate operational mechanism.
As a professional Wavefront Analyzer manufacturer and supplier in China, we have our own factory and offer reasonable prices. Whether you need advanced and newest products to meet the specific needs of your region or you want to buy high quality Wavefront Analyzer, you can leave us a message through the contact information on the webpage.
